2 Way Electric Ball Valve

2 Way Electric Ball Valve
2 Way Electric Ball Valve
Product Code : 03
Product Description

Facilitated by technically advanced process, we are offering a distinct range of 2 Way Electric Ball Valve that is designed to obtain perfect sealing, easy and quick operation. Offered relay ball valve is precisely manufactured by our experts using excellent quality metal and advanced technology as per the set industry standards. 2 Way Electric Ball Valve is demanded for common fluid control applications. Our customers can avail this ball valve from us in various specifications as per their exact requirements.

Electrical Actuator Specification

Power Supply : 230V AC

Rotation : 0 - 90°

Optional : Modulating 4 - 20 MA Input Signal & Output Signal

Limit Switch : 1 No + 1 Nc

Position Indicator : Provided

Maximum Temp.: -20°C + 70°C

Operating Time : 20 to 30 Sec

Valve Specification

Body : WCB / CF8 / CF8M

Ball : CF8 / CF8M

Design : 3 Piece Design

Seat : PTFE

Press.: 10 Bar Maximum

Temp.: 180°C

Ends : Flanged 150#
